DLMS Library

Terranova’s Smart Meter Libraries suite is designed for the implementation of some of the more important and widely used communication protocols such as DLMS/COSEM, MBUS, SML . The Libraries can be used for a wide range of applications, but mainly for the implementation of:

• Smart metering systems (server)
• Data collection systems (client)
• Data concentrators (client/server)
• Customized Stack Layers

DLMS LIBRARY - MAIN FEATURES

DLMS Library, component of the Smart Meter Libraries suite, is able to supply all the necessary software tools for rapid set-up of intelligent systems in multi service environments:

• Independent software package developed by using the ANSI-C (C89) programming language, in accordance with the MISRA-C syntax rules
• Object-Oriented module for organizing rough data in the server
• Scalable and modular architecture of the protocol stack
• Conforms to Green Book 10 and Blue Book 14: Push Service, Compact Frame, etc
• Partial data management (COSEM objects larger than the available memory can be handled)
• Includes definition of the more widely used OBIS codes (OBject Identification Sustem) and offers possibility of adding their customized versions
• Security Suite: AES-128, AES-192, AES-256; AES-GCM, AES-CBC, AES-CTR; CMAC, GMAC; CRC-16, CRC-32; ECDSA, ECDH, SHA256;
